冲压式秸秆蜂窝煤成型机主体结构设计

AbstractThe stamping straw honeycomb coal forming machine is to add straw to the dieplate,and then process the straw into shaped honeycomb coal by stamping.Thehoneycomb coal molding machine can choose from a variety of mechanisms and canmake a variety of design solutions.We innovate on the original basis of the stampingstraw honeycomb coal machine,so as to better achieve the function of the mechanism,that is,straw stamping and cleaning Crumbs,transported out shaped briquette.The design of each mechanism of the stamping straw honeycomb coal formingmachine should be reasonably analyzed and accurately calculated.At the same time,the designed parts must be able to operate normally after installation.In the designprocess of this subject,it is necessary to select each mechanism,and check and designthe transmission device,punching device,chip sweeping device and indexingmechanism.Use the knowledge of mechanical design,mechanical principles andother disciplines.【Key Words】Straw;mechanism;stamping
